品牌ITECH/艾德克斯

　　BK Precision直流电源

　　The 9150 series are high performance linear-regulated  programmable DC power supplies that provides excellent performance and features not found in other supplies in this price category. These supplies are designed for applications in design verification, production or university labs that require high yet clean and reliable power, combined with excellent resolution, accuracy and fast transient response time.Very low ripple and noise due to linear regulationExcellent display resolutionFast transient response time (<120 µs)SCPI compatibleCommunicate via RS232 or USB Interface, using included RS232 to TTL or USB to TTL serial converter cableClosed case calibrationList mode operation for increased throughputVery quiet due to inligent fan speed controlFor bench use or rack mountableApplication Software for front panel emulation and simple test sequence generation includedDigital port with Remote Inhibit (RI) useful for turning multiple power supplies On/Off simultaneouslyOver voltage protectionDigital Volt Meter and Milliohm MeterBK Precision直流电源

　　 BK9151 可供选择配件

　　RS232 to TTL Interface Cable

　　Model IT-E131

　　USB to TTL Interface Cable

　　Model IT-E132

　　Rack mount kit for select models

　　Model IT-E151

　　The IT-E151 is for rack mounting of compatible products in either a side-by-side configuration, or s single unit configuration where a provided blank is used to fill the empty space. The dimensions for the kit are 5.24" (133mm) by 19" (482.6mm).

　　High current premium test lead accessory

　　Model TLPWR1

　　High quality red and black cable with externally braided wrap with large fork-type spade connectors for connecting to high current power supplies or DC loads.Length: 2 mRated current: 60 AGauge: 8 AWGConnector inner diameter: 8 mm (approximate)Connector outter width: 15 mm (approximate)Wire material: flexible silicon jacket
